Housing and wheel core made of high quality Nylon –PA6, which with perfect load-bearing capacity, excellent oil resistivity, abrasive resistance, drug and chemical resistance for long life of our casters.
Product Description
Housing and wheel core made of high quality Nylon –PA6, which with perfect load-bearing capacity, excellent oil resistivity, abrasive resistance, drug and chemical resistance for long life of our casters.
Wheel tread made of TPU material. It shows better resistance to weathering, fatigue and high temperature, it assures of quiet and stable rolling.
|
Rolling smoothness |
● |
● |
● |
● |
○ |
|
Mute level |
● |
● |
● |
● |
○ |
|
Wear resistance |
● |
● |
● |
● |
○ |
|
Anti-rust properties |
● |
● |
● |
● |
○ |
Technical Data ℃/mm/Kg
| . Wheel diameter |
125 |
|
. Tread width |
32 |
|
. Hardle-∮ |
16 |
|
. Hardie length |
32 |
|
. Offset |
38 |
|
. Turning diameter |
201 |
|
. Total height |
165 |
|
. Temperature |
|
|
. Standard |
|
|
. Weight |
0.80kg |
|
. Load capacity |
125kg |
|
. Load capacity (static) |
250KG |
|
. Hardness of thread |
98A |
|
. Installed with thread |
M16*2 |
